FEATURES & SPECIFICATIONS
FEATURES:
iGene Laboratory freeze dryers are widely used in medicine, pharmacy, biology research, chemical industry and food production ,etc. After freeze drying process, a long term preservation for material is much easier. They can be restored to original state and maintain their chemical and biological characteristics after being watered. The vacuum freeze drying technology, which is also called sublimation drying, is a technical method that freezes the samples in advance, and then sublimates its moisture under vacuum state.
- Bench-top machine, suitable for drying products in bulk.
- Control panel display in English
- Vacuum can be displayed in Pa or Mbar
- Condenser with uniform and good ice capture function
- Acrylic drying Chamber is safe and easy to view sample status
- Small and compact structure , with easy and convenient operation
- Vacuum pump with high pumping speed , to reach good final vacuum
- Big opening condenser with external coiling tubes, has pre-freezing function
- Color LCD touch screen displays running time, display sample temperature, condenser temperature, vacuum degree, and save data automatically
- Display sample temperature curve, condenser temperature curve and vacuum curve
- CFC-free refrigerant, international famous brand compressor, low noise, good efficiency
- Condenser, trays, drying shelf and pre-freezing shelf are made of stainless steel 304, anti-corrosion
- Stainless steel air inlet valve (drain valve) is safe, anti-corrosion , no leak
- With USB port to output freeze drying data, open and view data in Excel format
SPECIFICATIONS:
| Models | IG-LZ10S | IG-LZ10T | IG-LZ10PT |
|---|---|---|---|
| Type | Standard chamber | TOP Press | TOP Press chamber with 8 port manifold |
| Freeze drying area | 0.12 ㎡ | ||
| Finalvacuum | 0.12 ㎡ | ||
| Ice Condenser capacity | 3-4 kg /24h | ||
| Condenser temperature | -80ºC | ||
| Final vacuum | < 10 Pa | ||
| Tray | Ф200mm,4 layers Spacing 70mm | ||
| Bulk capacity | 1.2L, 10mm thickness | ||
| Vial capacity Φ12mm | 820 pcs | ||
| Vial capacity Φ16mm | 460 pcs | ||
| Vial capacity Φ22mm | 244 pcs | ||
| Condenser size | Ф215mm, 140mm deep | ||
| Drying chamber size | Ф260×430mm | ||
| Vacuum Pump Flow Rate | 2 L/S, 7.2 m3/h | ||
| Defrosting | Off Cycle Defrosting | ||
| Cooling | Air cooling, ambient temperature≤25 ºC | ||
| Voltage | 220V /50 Hz,single phase | ||
| Power | 1400W (-80 ºC) | ||
| Dimensione | 850 x 680x (400+430)mm (-80 ºC) | ||
| weight | 130kg (-80 ºC) | ||
