ELISA Reader IG-96T

FEATURES and SPECIFICATIONS

DESCRIPTION
An ELISA reader is an instrument that is used to read the fluorescent, chemiluminescent, or chromogenic response of the ELISA in a 96-well plate. The instrument is designed to fit standard 96-well plates, and will provide quantitative information about the extent of the response for each individual well of the plate.

FEATURES:

  • Graphical operating interface, ergonomically designed for convenience of use.
  • High brightness and large size LED display, with touch screen input
  • Flexible Plate layout with Blanks, Standards, Samples, Reference, QC in one screen
  • Single board multiple tests function, performing 24 different tests at the same time just in one plate
  • Single or dual wavelength measurements, comprehensive qualitative and quantitative data- evaluation functions with cut-offs, curve-fits and transformation formulas
  • Proven optical system with 8 channel optical fiber scanning, auto plate centering system positions the center of the cell accurately
  • Auto Lamp adjustment and auto calibration, improve the efficiency of the system and reduce the cost
  • High sensitive touch screen input, and can be matched with the mouse and keyboard, support handwriting input
  • Multi-forms in data output ( local, USB, network), including text file and Excel file
  • Provide more than 20 different reporting formats including patient comprehensive report, support USB printers

SPECIFICATIONS:

Plate Style 48-hole,96-hole microplate or bar plate
Applicable hole Flat, V-bottom or U-bottom
Wavelength Range 400~800nm
Standard Filters 405,450,492,630nm
Additional Filters On request, filter wheel for up to 8 filters
Reproducibility ≤0.2%
Shaking Linear Shaking, 3 speeds
Screen 7 Inch colour LCD
Interface USB, VGA, NETWORK INTERFACE, AUDIO INTERFACE, RS-232
Read Speed Single wavelength ≤ 3s /96 holes
Power Supply 100~240V, 50~60Hz

PARAMETERS:

Light Source Controlled tungsten halogen lamp
Photodetector Silicon Photodiode
Indication Range 0.000~4.000OD
Accuracy ±1.0% at 1.0 OD, 450nm
Resolution 0.001OD
Stability ±0.003OD
Display 10.4 inch colour LED display, resolution 1024*600
Data Storage 2,000,000 test data, more than 500 test projects
Best Environment 5℃~40℃;max humidity:80%
Dimensions/Weight 460×350×197mm/10kg
